Huizhong Medical Technology Cold Storage Project

Shanghai Huizhong Medical’s 620m³ pharmaceutical cold storage project (2017) features dual-redundancy systems, ISO/IFCC compliance, and smart temperature control across 7 cool rooms and 1 freezer. Opt

Project Overview

Delivered a multi-layer pharmaceutical cold storage solution with redundancy and compliance for Shanghai Huizhong Medical.

Customer Industry Pharmaceutical Cold Room

Project location 上海

Capacity 620m³

Installation Layers 1F, 2F, 4F

Backup System Dual Redundancy

Temperature Range 2°C–8°C，≤-18°C

Certification ISO13485:2003, IFCC

Control System Smart Monitoring (Remote Alert)

Project Background/Challenges Faced

Temperature Stability: Ensuring strict ±2°C deviation in 7 cool rooms across 3 floors.
System Redundancy: Implementing 100% backup for critical refrigeration units.
Construction Coordination: Managing parallel insulation, refrigeration, and control system installations.

Solutions / Commissioning & Acceptance

Dual-Circuit Design: Independent refrigeration units for each floor with automatic switchover.
Smart Control Panel: Centralized monitoring with real-time alerts for temperature/humidity.
Phased Installation: Completed insulation first, followed by refrigeration and control systems post-CNY.

Project Results and Benefits

Energy Efficiency: 35% lower power consumption vs. industry average.
Compliance: 100% adherence to ISO13485 and IFCC standards.
Uptime: 99.9% system availability with redundant backups.

Achieved 35% energy savings and flawless compliance for multi-floor pharmaceutical cold storage.

The cold storage system’s stability and redundancy have been critical for our high-value diagnostic equipment. Zero downtime since launch. —— Quality Manager, Shanghai Huizhong Medical
